ZJWTP100DE for elcetrical winch with the truck,it is making heavy load and water protected.
※Brief technical data
|
|
parameters |
Coil & Rated volt of contact circuit(v) | |
|
12 |
24 | ||
|
1 |
Coil working current (A) intermittently for 5 mins |
2.2 |
1.1 |
|
2 |
Main rated load current of contact circuit |
Rated current 100A Max.Rated woring current of contact circuit for 4le,5seconds | |
|
3 |
Puncture(volt)strength |
50HZ 1000VAC 1min | |
|
4 |
Operating time |
Pickup(contact makes)≯30ms, release(contact breaks)≯30ms | |
|
5 |
Action characteristic |
Pickup(contact makes)≯66%Us, release(contact breaks)≯30%≮5%Us | |
|
6 |
Mechanical life |
100million times | |
|
7 |
Electric life |
Resistive load（τ＝１ms),1le,20000Ops; Inductive load（DC-5):1le,200Ops | |
1.Specifications subject to change as the customer request.
2.Coil voltage in above 48V with permanent magent blowouts.
