parameters

Coil & Rated volt of contact circuit(v)

6

12

24

30

36

40

48

72

80

1

Ｃoil hold current (A)

1.2

0.65

0.35

0.3

0.25

0.22

0.2

0.12

0.1

2

Coil start current(A)

Single coil product

3

Main rated load current of contact circuit

Rated current 100A

Max.Rated woring

current of contact circuit for 4le,5seconds

4

Puncture(volt)strength

50HZ 1000VAC 1min

5

Operating time

Pickup(contact makes)≯30ms,

release(contact breaks)≯30ms

6

Action characteristic

Pickup(contact makes)≯66%Us,

release(contact breaks)≯30%≮5%Us

7

Mechanical life

30million times

8

Electric life

Resistive load（τ＝１ms),1le,50000 Ops;

Inductive load（DC-5):1le,20000 Ops
