※Brief technical data
|
|
parameters |
Coil & Rated volt of contact circuit(v) | ||||||||
|
12 |
24 |
30 |
36 |
40 |
48 |
60 |
72 |
80 | ||
|
1 |
Ｃoil power dissipation<15(w),Max.Coil current (A) |
0.98 |
0.58 |
0.45 |
0.35 |
0.32 |
0.28 |
0.25 |
0.20 |
0.18 |
|
2 |
Main rated load current of contact circuit |
Rated current 100A Max.Rated woring current of contact circuit for 4le,5seconds | ||||||||
|
3 |
Puncture(volt)strength |
50HZ 1000VAC 1min | ||||||||
|
4 |
Operating time |
Pickup(contact makes)≯30ms, release(contact breaks)≯30ms | ||||||||
|
5 |
Action characteristic |
Pickup(contact makes)≯66%Us, release(contact breaks)≯30%≮5%Us | ||||||||
|
6 |
Mechanical life |
100million times | ||||||||
|
7 |
Electric life |
Resistive load（τ＝１ms),1le,50000Ops; Inductive load（DC-5):1le,10000Ops | ||||||||
1.Specifications subject to change as the customer request.
2.Coil voltage in above 48V with permanent magent blowouts.
