• High quality steel
plate with surface electrostatic spray.
• Integrated pump
with manual slow-down control valve.
• With imported seal
ring and chrome plated piston rod.
• Lubricating oil is
added on each active parts.
• With load capacity
1000kgs~5000kgs, safe and reliable. Applicable to work in narrow passageway.
Technical
Parameters:
Model
Standard
Heavy-loaded
Super-low
3.6
Super-low
5.5
Long
fork
Super
short
Load Capacity（Kg）
2000-3000
5000
1000
2000
1500-2000
2000-3000
Max.fork height（mm）
200
200
95
175
200
200
Lowered fork height（mm）
85
90
36
85
85
85
Fork Length（mm）
1150~1220
1150
1150~1220
1150~1220
1500-1800-2000
800-900-1000
Width overall forks（mm）
540-680
680
540-680
540-680
540-680
540-680
Front wheel (small) size and material (mm)
ф80×70
stainless
steel
nylon or PU wheel
Rear wheel size and material (mm)
ф200×50
stainless
steel
rubber, nylon or PU wheel
Product Applicability:
Hand Pallet Truck is widely applied in logistic business,
warehouses, factories, hospitals, schools, shopping malls, airports,
stadiums, and railway stations airports for short- distance
transportation.
