Model		BL-Q02	BL-Q05	BL-Q08	BL-Q10	BL-Q10B
PERFORMANCE	Type	4-Wheel, Back Drive, Hydraulic Brake System, MOFSET, Hand Brake
	Rated Tow Power	N	800N	1100N	1100N	2500N	2500N
	Towed Mass	KG	2000	5000	8000	10000	10000
	Drive Speed	(Full-Loaded) KM/H	11	10	8	8	8
	Turning Radius	MM	2200	2200	2200	2200	2200
	Gradeability	(Full-Loaded) (%×m)	10%×12m	10%×12m	10%×12m	10%×12m	10%×12m
WEIGHT	Load Distribute	Frond Wheel KG	420	492	492	630	630
		Rear Wheel KG	520	608	608	1180	1180
		Service Weight KG	940	1100	1100	1810	1810
		Load Rate Front: Back	0.45：0.55	0.45：0.55	0.45：0.55	0.35：0.65	0.35：0.65
MOTOR	Model		XQ-3-1	XQ-4.5	XQ-4.5	XQ-6.3	XQ-6.3
	Rated Power	KW	3	4.5	4.5	6.3	6.3
	Rated Voltage	V	45	45	45	45	45
	Rated Current	A	87	120	120	173	173
	Rated rotate speed	EPM	1780	1600	1600	1200	1200
	Excitation system	Series Excitation motor
SIZE	Overall Length	MM	1700	1700	1700	2095	2095
	Overall Width	MM	1130	1130	1130	1080	1080
	Overall Height	MM	1300	1300	1300	1390	1390
	Wheel base	MM	1030	1030	1030	1150	1150
	Tread	Front Wheel	980	980	980	920	920
		Rear Wheel	1000	1000	1000	890	890
	Ground Clearance		110	110	110	142	142
	Tow Rod Height	MM	320	320	320	365	365
TIRE	Tire	Front Wheel	145/70-R12/×2	145/70-R12×2	145/70-R12×2	6.50-10/×2	6.50-10/×2
		Rear Wheel	145/70-R12/×2	145/70-R12×2	145/70-R12×2	6.50-10/×2	6.50-10/×2

●  The practical work table raised the auxiliary work efficiency effectively.
●  New exempts the maintenance motor with moisture-proof, the dustproof protection.
●  Electron steering provides the precise control.
●  The self-braking causes the operation to be safer.
●  Special design's the space lets driver's work be more relaxed comfortably.
●  Seater electric tow，Convenience operation.
