The goods carriers are lifted by an electrical, infinitely adjustable lift drive, which is controlled on the module by means of a lift control button. During the lifting process, all functions can also be controlled from the operating panel on the tow tractor, if required. To ensure safety during operation, the train features a function to automatically lock the tow tractor when goods carriers are lowered, and a reduced cornering speed is applied. This reduced cornering speed remains in effect until the axle on the last module is travelling straight again. To make cornering easier and to keep the necessary turning radius as small as possible, the steering angle between two goods carriers can be increased to 120 degrees. In addition to the limited option for reverse travel, another notable feature is the crab steering, which is available as an option. Using this function, the entire train can be driven on a lateral slope.

Criteria such as the condition, width and slope of the drive path, the type of storage area (e.g. cold store, clean room, or storeroom for edible produce) as well as dimensions, weight, fragility and container packaging, all determine the specific manner in which the two Linde trains should be set up. Not least, the travel route and set-up of the other logistics operations within the company play an important role in determining which solution best meets requirements.
