型号 Model |
单位 Uniss |
CDD1.0A | ||
|
额定起重量 Rated lifting capacity |
Kg |
Q |
1000 | |
|
载荷中心距 Load centre |
mm |
C |
500 | |
|
最大起升高度 Max.lifting height |
mm |
H |
2500/3300 | |
|
起升速度 （空载/满载） Max.lifting speed (empty/laden) |
mm/s |
100/80 | ||
|
最小转弯半径 Min.outside turming radias |
mm |
R |
1550 | |
|
行驶速度 Travel speed |
km/h |
0-5.5 | ||
|
作业时最大高度 Max.operation height |
mm |
A |
3050/3450 | |
|
外型 尺寸 Overall dimension |
长Length |
mm |
L |
1750 |
|
宽Width |
mm |
W |
850 | |
|
高Height |
mm |
H |
1800/2150 | |
|
货叉长度Fork length |
mm |
L |
1000 | |
|
货叉内宽 Interdistance between forks |
mm |
E |
220/320 | |
|
货叉外宽 Opening of forks |
mm |
D |
580/680 | |
|
货叉最低位高度Min.height of fork |
mm |
H |
<90 | |
|
蓄电池 Battery |
电压Voltage |
V |
24 | |
|
容量Capacity |
Ah |
210 | ||
|
电机 |
行走Driving |
KW |
0.55 | |
|
起升Lifting |
KW |
2 | ||
|
速度调制方式 Mode of speed control |
VMOS | |||
|
自重Vet weight |
kg |
820/870 | ||
